COM Express, Type 6, Atom E3845, DDR3L, 0°C~+60°C

Kod produktu: conga-TCA3/E3845

Cechy produktu:

* Produkt wycofany przez producenta. Prosimy o kontakt z naszymi handlowcami

* Sugerujemy zamiennik z serii conga-TCA7

  • COM Express Type 6 Compact module
  • Intel® Atom™ E3845 quad core processor with 1.91GHz, 2MB L2 cache
  • 1333MT/s dual channel DDR3L memory interface.
Ordering information
P/N Article Description
047300 TCA3/E3845 COM Express Type 6 Compact module with Intel® Atom™ E3845 quad core processor with 1.91GHz, 2MB L2 cache and 1333MT/s dual channel DDR3L memory interface.



Optional accessories
P/N Article Description
047350 TCA3/HSP-T Standard heatspreader for COM Express modules conga-TCA3 and TCA4. All standoffs are M2.5 thread.
047351 TCA3/HSP-B Standard heatspreader for COM Express modules conga-TCA3 and TCA4. All standoffs are 2.7mm bore hole.
047352 TCA3/CSP-T Standard passive cooling solution for COM Express modules conga-TCA3 and TCA4 with 20mm overall heat sink height. All standoffs are M2.5mm thread.
047353 TCA3/CSP-B Standard passive cooling solution for COM Express modules conga-TCA3 and TCA4 with 20mm overall heat sink height. All standoffs are 2.7mm bore hole.
065810 TEVAL2 Evaluation Carrier Board for COM Express Type 6 modules.
065830 IT6/COMe Carrier Standard Mini-ITX carrier board for COM Express Type 6 modules.
065840 IT6/IO Shield IO shield for conga-IT6/COMe Carrier board with standard Mini-ITX height.
068755 DDR3L-SODIMM-1600 (2GB) DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S) and 2GB RAM
068756 DDR3L-SODIMM-1600 (4GB) DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S) and 4GB RAM
068757 DDR3L-SODIMM-1600 (8GB) DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S) and 8GB RAM
068782 DDR3L-SODIMM-1600 (2GB) industrial Industrial DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S) and 2GB RAM
068783 DDR3L-SODIMM-1600 (4GB) industrial Industrial DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S) and 4GB RAM
068784 DDR3L-SODIMM-1600 (8GB) industrial Industrial DDR3L SODIMM memory module with 1600 MT/s (PC3L-12800S) and 8GB RAM
