2-port RS-232/422/485 Serial Device Server
Kod produktu: EKI-1522
Cechy produktu:
– Supports 2 x 10/100Base-T redundant Ethernet networking
– Provides COM port redirection (Virtual COMport), TCP and UDP modes
– Supports baud rate up to 921 kbps
– Allows a max of 5 hosts to access one serial port
– Supports an advanced security mechanism to avoid unauthorized access
– Allows a max of 16 hosts to access TCP client and command response mode
– Download and testing utility: Easy to download firmware and self-diagnosis
– Easily manage Port Mapping and configuration utility for WinNT/2000/XP
– Mounts on DIN-rail, or panel
– Automatic RS-485 data flow control
EKI-1521 and EKI-1522 feature two independent Ethernet ports and MAC addresses to provide a redundant networking mechanism to guarantee Ethernet networking reliability. EKI-1521 and EKI-1522 are serial device servers that connect RS-232/422/485 serial devices, such as PLC, meters, sensors, and bar code reader to an IP-based Ethernet LAN. They allow nearly any device with serial ports to connect and share an Ethernet network. EKI-1521 and EKI-1522 provide various operations: COM port redirection (Virtual COMport), TCP Server, IP Client and UDP mode. With COM port redirection mode, standard serial operation calls are transparently redirected to the EKI-1521 and EKI-1522, guaranteeing compatibility with legacy serial devices and enabling backward compatibility with existing software. With TCP server, TCP client, and UDP modes, EKI-1521 and EKI-1522 ensures the compatibility of network software that uses a standard network API. Moreover, you can make serial devices communicate with other devices peer-to-peer, without any intermediate host PCs and software programming.
